Viberant Owner’s Manual6-
System Wiring
head unit
L/R Audio
Outputs
LEFT speaker
RIGHT speaker
To Remote Output
From Head Unit
To Battery
SPEAKER
IMPEDANCE
4 OHMS!
2 CHANNEL STEREO CONFIGURATION
vibe218/228/238/248/258/268
FRONT
REAR
(vibe218 without
Remote Bass Boost)
