Viberant Owner’s Manual8-
System Wiring
2 CHANNEL TRI-MODE CONFIGURATION
vibe218/228/238/248/258/268
FRONT
REAR
LEFT
speaker
Speaker
To Remote Output
From Head Unit
To Battery
SPEAKER
IMPEDANCE
4-8 OHMS!
head unit
(vibe218 without
Remote Bass Boost)
RIGHT
speaker
