No.ARTICLE QUANTITÉ No.PIÈCE DESCRIPTION
1 1 1307707 PLAQUE SB T75 B MAGAZ SUPPORT BASE PC75
2 2 1307598 ROUL 608 EE 8x22x7 BEARING 608 EE 8-22-7
3 1 1307529 PASTILLE BLOCAGE PIGEON T85 BLOCK PIGEON RUBBER T85
4 1 1307636 CARRE DE CENTRAGE C CENTERING SQUARE
5 1 1307709 SUP BLOC PIGEON CLAY BLOCK SUPPORT MINI PC75
6 1 1307710 BLOC PIGEON CLAY HOLDER MINI PC75
7 1 1400000 TIGE FILETEE 06-110 ROD 06-110
8 1 1302155 RESSORT BUTEE 135 75 STOP SPRING 135 JTA
9 1 1307726 ANTI CHUTE T75 A ANTI NO BIRD
10 13 1400047 RD PLT MOY AZ 06-014-1.2 FLAT WASHER MED AZ 06-014-1.2
11 12 1400024 ECROU INDES AZ 06-000 SPRING ACTION LOCK NUT 06
12 2 1400314 RD LARGE AZ 06-018-1 LARGE WASHER AZ 06-018-1
13 3 1400002 ECROU HU CL8 06-000 NUT HU CL8 06-000
14 2 1400128 VIS TH8.8 06-030 SCREW TH8.8 06-030
15 2 1400447 VIS TH8.8 06-050 SCREW TH8.8 06-050
16 2 1400126 VIS TH8.8 06-020 SCREW TH8.8 06-020
17 4 1400049 RD PLT MOY AZ 10-022-2 FLAT WASHER MED AZ 10-000
18 2 1400148 VIS TH6.8 10-030 SCREW TH6.8 10-030
19 2 1400026 ECROU INDES AZ 10-000 SPRING ACTION LOCK NUT 10
20 1 1112360 MICRO-CONTACT ARM MICRO SWITCH LOADING MOTOR
25 2 1400409 VIS TCHC 8Z 04-025 SCREW TCHC 8Z 04-025
26 2 1400022 ECROU INDES AZ 04-000 SPRING ACTION LOCK NUT 04
27 2 1400045 RD PLT MOY AZ 04-000 FLAT WASHER MED AZ 04-000
28 1 1307383 RES TRAC DIA 13 T85 TRACTION SPRING MIDI D13
29 1 1307622 BRAS DROIT T65 H RIGHT ARM T65
30 2 1111090 PASSE FIL DIA 8 PASSE FIL DIA 8
31 1 1400208 VIS TFHC 8Z 06-025 SCREW TFHC 8Z 06-025
32 1 1307623 BRAS GAUCHE T65 K LEFT ARM
EASYTRAP 75
S ENS PLAQUE SB T75
C:\sébastien\Solidworks\ACTUEL\EASY TRAP 75\S ENS PLAQUE SB T75\
11.07.2005
PAGE 2/2
Note: Certain spare parts
are not sold separately.
ATTENTION: Certaines pièces ne peuvent
êtres vendues séparément.
Les pièces précedées du signe + ne sont
pas vendables.
