Larius Giotto - Cleaning at the End of the Work

9
GIOTTO
English
H
H1
OFF
H2
CLEANING AT THE END WORK
• Reduce pressure to the minimum (turn counterclockwise the
pressure control knob (H1) ).
• Press the ON/OFF switch (H2) placed on the box of the
electric motor, to stop the equipment.
• First release the residual pressure from the gun by holding
it pointed down towards the paint container, then open the
re-circulation valve.
• Lift the suction pipe and replace the product tank with that
of the solvent (ensure it is compatible with the product being
used).
• Unscrew the gun nozzle (do not forget to clean it with solvent!).
• Turn the ON-OFF switch (H2) on the ON position and
rotate the pressure setting knob (H1) slightly clockwise.
• Make sure the solvent recycles the washing uid from the
return tube.
• Close the re-circulation valve.
• Point the gun at the product tank and, keeping the trigger
pressed, release the remaining product till a clean solvent
comes out. Now, release the trigger.
• Lift again the suction pipe and remove the solvent tank.
• Now point the gun at the solvent tank and press the trigger
so as to recover the residual solvent.
• As the pump starts idling, press the ON/OFF switch to
stop the equipment.
• In case of long storage, we recommend you to suck and
to leave light mineral oil inside the pumping group and the
exible hose.
Follow the washing procedure before using again
the equipment.
