Lascar Electronics EasyLog - LED Status Indicators; EL-USB LED Status Indicators; EL-USB-LITE LED Status Indicators; EL-USB-1-RCG LED Status Indicators

For a full product datasheet for your data logger
or for more information on the rest of the EasyLog range visit
www.lascarelectronics.com/data-loggers
Temperature
Temperature/
Relative Humidity
Event, State &
Count
Thermocouple
Voltage
Current
Carbon Monoxide
Thermistor
IMPORTANT SAFETY INFORMATION
Disposal and Recycling Information
You must dispose of Lascar products in accordance with relevant laws and regulations. They contain
electronic components and lithium batteries and therefore must be disposed of separately from
household waste.
Repairing or Modifying
Never attempt to repair or modify Lascar products. Dismantling them, other than for the purpose of
changing replaceable batteries, may cause damage that is not covered under the warranty. Servicing
should only be provided by an authorized supplier.
EL-USB-LITE
Green single ash
The data logger is
currently logging. No
alarm.
Red single ash
The data logger is
currently logging. Low
alarm.
Red double ash
The data logger is
currently logging. High
alarm.
No LEDs ash
The data logger is
stopped, the baery
is empty or there is no
baery ed.
EL-USB (excluding EL-USB-1-PRO)
Green double ash
The data logger is not cur-
rently logging, but is primed
to start at a later date and
me (delayed start).
Green single ash
The data logger is currently
logging. No alarm.
Green and Amber single ash
The data logger is full and has
stopped logging. No alarm.
Red single ash
The data logger is currently
logging. Low alarm.
Red and Amber single ash
The data logger is full and has
stopped logging. Low alarm.
Red double ash
The data logger is currently
logging. High alarm.
Red and Amber double ash
The data logger is full and has
stopped logging. High alarm.
Amber single ash
The baery is running low.
Data logging will connue
unl the baery voltage
drops below 2.8V.
No LEDs ash
The data logger is stopped,
the baery is empty or there
is no baery.
Red double ash
The data logger is
currently logging. High
alarm.
No LEDs ash
The data logger is
stopped, the baery
is empty or there is no
baery ed.
Green single ash (every 30s)
The data logger is not currently
logging, but is primed to
start at a later date and me
(delayed start)
Green single ash (every 10s)
The data logger is currently
logging. No alarm.
Red single ash (every 10s)
The data logger is currently
logging. Low alarm.
Red double ash (every 10s)
The data logger is currently
logging. High alarm.
Green single ash (every 20s)
The data logger is currently
logging. Low baery.
Red single ash (every 20s)
The data logger is currently
logging, however the baery is
running low. Low alarm.
Red double ash (every 20s)
The data logger is currently
logging, however the baery is
running low. High alarm.
Green double ash (every 20s)
The data logger is full and has
stopped logging.
Red & Green single ash
alternately (every 20s)
The data logger is full and
has stopped logging. High or
low alarm.
No LEDs ash
The data logger is stopped, the
baery is empty or there is
no baery.
EL-USB-1-RCG
