Laser 7323 User Manual

• Equivalent to OEM tools 303-1637, 303-1650, 303-1643.
• For high pressure fuel pump pulley removal, please see Laser Part No. 7324 &
Vibration Damper Pulley Puller - Laser Part No. 7334.
2
www.lasertools.co.uk
Components
Introduction
This timing kit has been designed for the latest Ford 2.0D EcoBlue TDCi engine
which features an innovative “belt in oil” design where the synchronous drive belt is
sited inside the oiled area of the engine. The kit consists of the crankshaft alignment,
Flywheel locking and belt fitting tools required to remove and refit the timing belt
without damage.
Ref Code OEM Description
A C863 303-1643 Flywheel Holding Tool
B C864 303-1637 Crankshaft Alignment Tool
C C865 303-1650 Installation Cups
D C050 6mm Alignment Pins (3)
