LaserLiner 082.114A - First Use

VideoScope XL
5
2.0x
+
a
b
c
AA
AA
AA
AA
4x AA
1 432
LCD
a Battery status
b Zoom level
c Intensity of LED lighting
(5 brightness levels)
1 LCD
2 ON/OFF
3 Hot keys
4 Operation indicator
a Zoom in
b Zoom out
c Rotation 180° /
Mirroring
d LED lighting +
e LED lighting –
5 Battery compartment
6 Camera head
7 LED
8 Lens
07
EN
2
3
1
5
4
7
8
6
3
a c d
eb
NOTE: The VideoScope XL delivers sharp images in a range between 3 and 7 cm from the camera head.
Objects outside this range may appear blurred.
4
ON/OFF
First use
