11
AirflowTest-Master
2
m
2
m
2
m
6
The outlet area of the ow source must rst be
dened before determining volumetric ow.
After switching on by pressing the „MODE“
button, activate the function for measuring
volumetric ow until „AREA“ appears on the
display. The rst number begins to ash. Use
the „5“ (+) and „SET“ (change decimal place)
buttons to enter the determined area.
The area can be set both in square metres (m²)
as well as in square feet (ft²). The end of the
input is signalled by a double beep.
Activate the „FLOW“ function by pressing
the „MODE“ button. After selecting the
corresponding unit – CMM (cubic metres
per minute), CFM (cubic feet per minute)
and CMS (cubic metres per second) –
press the „UNIT“ button to determine the
volumetric ow based on the set area.
Volumetric flow
GB
The „MODE“, „UNIT“ and „MIN/MAX“ functions are deactivated while
the „HOLD“ function is activated. These functions are available again
after pressing the „HOLD“ button once more.
!
Air ow
The „MODE“, „UNIT“ and „MIN/MAX“
functions are deactivated while the
„HOLD“ function is activated. These
functions are available again after
pressing the „HOLD“ button once more.
!
