12
Technical data (Subject to technical alterations)
Self-levelling range ± 4°
Precision ± 4 mm / 10 m
Horizontal / vertical levelling
Automatic with electronic sensors
and servo motors
Self-levelling alignment time
Approx. 50 seconds over the entire
operating angle
Vertical reference beams 90° to rotation plane
Rotation speed 0, 150, 300, 600 rpm
Laser wavelength 635 nm
Laser class 2 (EN60825-1:2007-10)
Laser output rating < 1 mW
Power supply Alkali batteries (4x type AA)
Non-rechargeable battery life approx. 12 h
Operating / storage temperature -10°C ... + 40°C / -10°C ... + 70°C
Dimensions (W x H x D) /
Weight (incl. battery)
155 x 130 x 150 mm /
0,75 kg
Tips and tricks for working with the AutoSmart-Laser
– Use a height which is not interrupted by glass or windows so as to avoid
reflections.
– Generate a working mark (reference height)
in order to always continue working from
the same height.
– When working outdoors, position the device on
the highest point so as to overcome obstacles.
– The laser enhancement glasses (Art. No. 020.70A)
will enable you to see the laser beam much more
clearly.
– When installing separating walls, align the
reference beam parallel to the wall (see Fig. 1).
– For ceiling work, the height-adjustable wall
mount (Art. No. 080.71, Fig. 2) is an
indispensable aid.
GB
1
2
