ClampMeter XP
EU directives and disposal
This device complies with all necessary standards for the free movement
of goods within the EU.
This product is an electric device and must be collected separately
for disposal according to the European Directive on waste electrical
and electronic equipment.
Further safety and supplementary notices at:
http://laserliner.com/info?an=cmxp
Function Range Resolution
Accuracy
% of measured value (rdg)
+ least significant digits
Temperature
-148 … 1832°F 0.1°F ± (1% rdg ± 4.5°F)
-100 … 1000°C 0.1°C ± (1% rdg ± 2.5°C)
Function Range Max. input
AC current
Accuracy specified for 5% … 100%
of measured value
1000 A
DC current 1000 A
Function Range Input protection
AC voltage (Auto range)
500 mV 600 AC/DC
5V/50/500/1000 V 1000 AC/DC
Frequency: 50 Hz ... 1000 Hz
DC voltage
500 mV 600 AC/DC
5V/50/500/1000 V 1000 AC/DC
Resistance (Auto range) 600V AC rms or 600V DC
Capacitance (Auto range) 600V AC rms or 600V DC
Clamp opening 48 mm
Diode test
Test current/voltage ≤ 0.3 mA /
open circuit voltage < 2 V DC typical
Continuity test Response threshold < 35Ω + 5Ω, test current < 0,5 mA
LCD 0 … 50000
Measurement range 3 measurements/sec.
Input resistance 1,0 MΩ (VDC, VAC)
Protection class II, double insulation
Overvoltage category CAT III - 1000V, CAT IV - 600V
Pollution degree 2
Operating conditions 5 ... 40°C, 80%rH, no condensation, max. altitude 2000 m
Storage conditions -20 ... 60°C, 80%rH, no condensation
Radio module operating data
Bluetooth LE 4.x interface Frequency band: ISM band 2400 –
2483.5 MHz, 40 channels Transmission power: max. 10mW
Bandwidth: 2 MHz Bit rate: 1 Mbit/s; Modulation: GFSK/FHSS
Power supply 1 x 6LR61 9V
Dimensions (W x H x D) 76 x 230 x 40 mm
Weight (incl. batteries) 496 g
27
EN
