Information on maintenance and care
Clean all components with a damp cloth and do not use
cleaning agents, scouring agents and solvents. Remove the
battery(ies) before storing for longer periods. Store the device
in a clean and dry place.
Subject to technical alterations. Rev23W40
Technical data
Detection range AC 110 - 230V, 50 - 60 Hz
Indicators LED (red/green), LCD bar display
Power supply 1 x 9V 6LR61 (9V block)
Operating time approx. 7 hours
Operating temperature
0°C … 40°C, max. humidity
80% rH, no condensation, max.
working altitude 2000 m above
sea level
Storage temperature
-20°C … 70°C, max. humidity
80% rH
Dimensions (W x H x D) 85 mm x 180 mm x 38 mm
Measuring depth
Targeted metal location:
Ferro-Scan / Non-Ferro-
Scan (METAL-SCAN)
Up to 7,5 cm /
up to 5 cm depth
Targeted location of live
supply lines (AC-SCAN)
Up to 4 cm depth
Location of dead
supply lines
Up to 4 cm depth
