LaserLiner CompactCross-Laser Pro User Manual

19
CompactCross-Laser Pro
Technical data
Subject to technical alterations. 19W24
Self-levelling range ± 4°
Accuracy
± 0.35 mm / m
Operating range 20 m (depending on room illumination)
Operating range with hand
receiver
40 m (depends on how the technology
affects the difference in brightness)
Laser wavelength 515 nm
Laser class 2 / < 1 mW
Power supply
2 x 1.5V LR6 (AA)
Operating time approx. 3 h
Operating
conditions
0°C ... 50°C, max. humidity 80% rH,
no condensation, max. working altitude
4000 m above sea level
Storage conditions -10°C ... 70°C, max. humidity 80% rH
Radio module
operating data
Bluetooth LE 4.x interface;
Frequency band: ISM band
2400–2483.5 MHz, 40 channels;
Transmission power: max. 10 mW;
Bandwidth: 2 MHz; Bit rate: 1 Mbit/s;
Modulation: GFSK/FHSS
Dimensions (W x H x D) 75 x 88 x 58 mm
Weight 246 g (incl. batteries)
EU directives and disposal
This device complies with all necessary standards
for the free movement of goods within the EU.
This product is an electric device and must be
collected separately for disposal according to
the European Directive on waste electrical and
electronic equipment.
Further safety and supplementary notices at:
http://laserliner.com/info/?an=AHV
EN

LaserLiner CompactCross-Laser Pro Specifications

General

Laser Class	2
Wavelength	635 nm
Accuracy	±0.2 mm/m
Working Range	10 m
Self-Leveling Range	±4°
Battery Type	AA
Weight	0.68 kg
Protection Class	IP54
