Read the operating instructions and the enclosed brochure
„Guarantee and additional notices“ completely. Follow the
instructions they contain. This document must be kept in a
safe place and if the laser device is passed on, this document
must be passed on with it.
!
Compact laser distance meter for measuring length,
area and volume – with angle measurement function
DISPLAY:
a
b
c
d
e
f
Settings menu
Unit of measure
m / ft / inch / _‘ _“
Measurement point (reference)
rear / thread / front
Continuous measurement /
Length measurement
Pythagoras 1
Pythagoras 2
g
h
i
j
k
l
m
Area measurement
Volume measurement
Angle function 1
Angle function 2
Measured value, angle function
Intermediate values
Measurement values /
Measurement results
Unit m / ft / inch / _‘ _“
1.
2.
KEYPAD:
Measure
ON / OFF
EN
27.1°
a
b
c
d jihfe
g
k
l
m
