LaserLiner LaserRange-Master T3 Operating Instructions

14
1x 2x
27.1°
Angle function 2:
Angle function 2 1. measurement 2. measurement result
height
The measurement result is determined by the 360° inclination sensor.
The back of the device can be used as a reference surface for
measuring angles.
!
EN
Err204:
Err208:
Err220:
Err252:
Err253:
Err255:
Err256:
Err261:
Err500:
Important notices
• The laser points to the location that will be measured.
No objects may get into the laser‘s line of measurement.
• The device compensates the measurement for different room
temperatures. Therefore allow the device a brief adaptation period
when changing locations with large temperature differences.
• The device is only conditionally useable in outdoor areas and cannot
be used in strong sunlight.
• The measurement results of outdoor measurements may be influenced
or falsified by rain, fog and snow.
• In unfavourable conditions, e.g. with poorly reflecting surfaces, the
maximum deviation may be greater than 3mm.
• Carpeting, upholstery or curtains will not reflect the laser optimally.
Measure to flat surfaces.
• Measurements made through glass (window panes) can falsify
measurement results.
• An energy-saving function switches the device off automatically.
• Clean with a soft cloth. Water may not be allowed to penetrate
the housing.
Error codes:
Calculation error
Internal fault
Replace the battery
Temperature is too high: > 40°C
Temperature is too low: < 0°C
Received signal too weak or measuring time too long
Received signal too strong
Outside the measuring range
Hardware fault

LaserLiner LaserRange-Master T3 Specifications

General

Type	Line level
Product color	Black
Display type	Digital
Maximum range	30 m
Leveling accuracy (±)	2 mm/m
Distance measuring units	m
Self-leveling range (±)	- °
Accuracy	2 mm
Minimum measurement distance	02.2 m
Battery type	-
Battery included	Yes
