ThermoXplorer Pro
27
1 2 3 4
5 12
6 87 9 10 11
1413
15 16
1
3 sec
2
3
1.
2.
GB
Standard measurement view
1 Set emissivity coefcient
2 Date
3 Time
4 Determine temperature mode
(man./auto..)
5 Micro-SD card inserted
6 Used memory space (Micro-SD card)
7 Thermography image
8 Min. temperature
9 Colour spectrum
with temperature range
10 Max. temperature
11 Temperature unit
12 Battery charge indicator
Main menu
13 Add measurement points,
lines and areas
14 Temperature range
automatic / manual
15 General and measurement-
specific settings
16 Media gallery
Measurement
Level/Span
Setup
File
ON / OFF
Charging the li-ion battery
Replace li-ion battery
To replace the li-ion battery, unlock the
handle (see image on right). Remove the
battery pack, insert the new battery pack
and lock the compartment again.
Store the battery packs in the holders in the case when transporting the camera
or when the camera is not used for longer periods.
!
