Laserworld CS-2000RGB - DMX Channel Functions; Channel 1: Mode Selection; Channel 2: Pattern Selection; Channel 3: Strobe Effect

Manual: Club Series CS-1000RGB / CS-1000RGB SE / CS-2000RGB / CS-2000RGB SE / CS-4000RGB / CS-4000RGB SE
page 9 / 22
Channel Value Function
1 0-63 Laser o
64-127 sound mode
128-191 automatic mode
192-255 DMX mode
2 0 - 255 Patterns
3 0 - 255 Eect channel: Strobe
Horizontal movement
4 0 no eect
1-167 (xed) movement
168-188 animated left to right with increasing speed
189-209 dto. right to left
210-255 dto. left to right and back.
5 0 - 255 vertical movement: analogous to horizontal
movement
Zoom
6 0-10 no eect
11-104 increasing size
105-154 growing with increasing speed
155-204 dto. shrinking
205-255 dto. growing/shrinking
Width (rotation over Y)
7 0-150 xed rotation
151-255 automatic rotation with increased speed
8 0 - 255 Height (rotation over X): analogous to width
Rotation
9 0-180 xed rotation
181-217 automatic with increased speed clockwise
218-255 do. counter clockwise
