Install the supplied wall-mount screws
into a wall by using the template.
Be sure to keep about 6 mm of the screw
head away from the wall.
Step 1
Unlock the key and remove the cover.
And then hang it on the wall.
Step 2
Replace the cover and lock.
Step 3
WALL MOUNTING
Caution: The supplied screws are intended for use on a thick wooden wall or wooden column.
Do not use them on any other materials. The time clock may come off if used on other materials.
Just as with an AM radio, the Model 1500E can be positioned for optimal reception. For instance,
it is best to position the clock away from metal studs and toward the direction of the tower in
Colorado.
WALL
WALL
WALL
(Upper side)
