6.5.4 Other error messages
−
Other error messages shown on display.
EEE
changes with
error code, e.g. 0
!
various temperature probe faults.
!
pump fault, proceed as in Section 6.5.3.
☞
−
If the fault report is repeated
!
pull out the mains plug and try whether the motor
can be rotated by the fan blade inserting a screwdriver into the ventilation opening
at the back of the unit.
−
Error code 0 ...255
!
microprocessor error.
−
Error code 1000...1255
!
slave processor error.
−
Indication can be used for remote diagnosis.
−
After rectifying the fault, reset with the key.

Lauda RE 104 Specifications

General

Pump capacity flow rate	15 L/min
Bath volume	4.5 L
Temperature stability	±0.01 °C
Circulation pump flow rate	15 L/min
Power supply	230V 50Hz
