Launch TWC-581 User Manual

LAUNCH                                                                  TireChangerTWC-581

24

118

103020148 HexagonboltM12×35
119

103040044 Springwasherφ12
120

103020169 HexagonboltM12×60
121

201021016 Pinsocketassembly
122

103990167 Resilientclip
123

103050002 Circlipforshaftφ12
124

103040112 Plainwasherφ12 
125

103202023 Positionsleeve
126

201012269 Axis
127

104130258 YSealingring28×20×5
128

202010068 Guidesleeve
129

201011915 Clampingcylinderpistonrod
130

103220082 Frontcoverofclampingcylinder 
131

104130081 OSealingringφ65×2.65
132

103040112 Plainwasherφ12 
133

104130053 Clampingcylinderpiston
134

103040112 Plainwasherφ12 
135

103040044 Springwasherlighttypeφ12
136

103030061 NutM8
137

103010327 HexagonsocketscrewM8×25
138

103040049 Springwasherφ8
139

103040064 Plainwasherφ8
140

103230054 Backcoverofclampingcylinder
141

103220089 Clampingcylinderbody
142

103100242 Nutlocking  Ljoint
143

201020987 Clampingcylinderassembly
144

103100242 Nut3waypipejoint
145

104050033 Aircompressinghose
151

201021013 Workingdeckassembly
152

201021015 Turntableassembly
201

Y103230037

Beadbreakercylinderbody
202

103030106 LocknutM16
203

103040117 Plainwasherφ16
204

103230035 Beadbreakercylinderpiston
205

104130055 High

lowlipring
206

104130061 OSealingringφ16×2.65
207

103040117 Plainwasherφ16
208

201010172 Beadbreakercylinderpistonrod 
209

104130060 OSealingringφ180×3.55
210

103230168 Beadbreakercylindercover
211

104130079 OSealingringφ19×2.65
212

202010068 Guidesleeve
213

201010179 Setscrew
214

103040112 Plainwasherφ12 
