EN - 12
• The terminal box connection is placed
on the terminal box.
4
4
N
N PE
PE
L2
L3
L1
L
5 5
3
3
2
2
1
1
• Installation of the yellow-green
grounding cable should be done as
shown in the picture using the screw
and washer located in the document
bag. This procedure should be applied
when the oven is installed.
a Nut c Washer
b Grounding cable d Screw
a
c
d
b
