Lauterbach MMDSP User Manual

MMDSP Debugger 2 9
©1989-2019 Lauterbach GmbH
CPU specific TrOnchip Commands
TrOnchip.CONVert Adjust range breakpoint in on-chip resource
The on-chip breakpoints can only cover specific ranges. If a range cannot be programmed into the
breakpoint, it will automatically be converted into a single address breakpoint when this option is active. This
is the default. Otherwise an error message is generated.
TrOnchip.VarCONVert Adjust complex breakpoint in on-chip resource
The on-chip breakpoints can only cover specific ranges. If you want to set a marker or breakpoint to a
complex variable, the on-chip break resources of the CPU may be not powerful enough to cover the whole
structure. If the option TrOnchip.VarCONVert is set to ON, the breakpoint will automatically be converted
into a single address breakpoint. This is the default setting. Otherwise an error message is generated.
TrOnchip.state Display on-chip trigger window
Opens the TrOnchip.state window.
Format: TrOnchip.CONVert [ON | OFF]
TrOnchip.CONVert ON
Break.Set 0x1000--0x17ff /Write
Break.Set 0x1001--0x17ff /Write
…
TrOnchip.CONVert OFF
Break.Set 0x1000--0x17ff /Write
Break.Set 0x1001--0x17ff /Write
; sets breakpoint at range
; 1000--17ff sets single breakpoint
; at address 1001
; sets breakpoint at range
; 1000--17ff
; gives an error message
Format: TrOnchip.VarCONVert [ON | OFF]
Format: TrOnchip.state
