AssemblingtheGrassBag
NoPartsRequired
Procedure
1.Slipthegrassbagovertheframeasshownin
Figure7.
g027543
Figure7
1.Handle
3.Grassbag
2.Frame
Note:Donotslipthebagoverthehandle
(Figure7).
2.Hookthebottomchannelofthebagontothe
bottomoftheframe(Figure8).
g027544
Figure8
3.Hookthetopandsidechannelsofthebagonto
thetopandsidesoftheframe,respectively
(Figure8).
