To Next PageTo Next PageWhy Lawn-Boy Lawn Mower engine will not start?
If your Lawn-Boy lawn mower engine won't start, try these steps: First, fill the fuel tank with fresh gasoline. Next, press the primer three times. Ensure the spark plug wire is connected. Finally, clean the spark plug, check its gap, and replace it if it's damaged.
What to do if Lawn-Boy Lawn Mower engine starts hard or loses power?
If your Lawn-Boy lawn mower engine starts hard or loses power, try the following: drain and refill the fuel tank with fresh gasoline, clean the gas cap vent hole, replace the air filter element (if you have models 10200, 10249, 10313, 10321) or clean air filters (if you have models 10248, 10327, 10328, 10330), clean the mower discharge chute and the underside of the mower deck, clean the spark plug (checking the gap and replacing if damaged), and check the engine oil.
How to fix Lawn-Boy Lawn Mower that will not self-propel?
If your Lawn-Boy lawn mower will not self-propel, try adjusting the self-propelled cable and clean any debris under the belt cover.
Why Lawn-Boy Lawn Mower engine runs rough?
If your Lawn-Boy lawn mower engine is running rough, make sure the spark plug wire is connected. Also, clean the spark plug, check the spark plug gap, and replace the spark plug if damaged. Replace the air filter element if you have models 10200, 10249, 10313, or 10321, or clean the air filters if you have models 10248, 10327, 10328, or 10330.
What to do if Lawn-Boy Lawn Mower vibrates excessively?
If your Lawn-Boy lawn mower or engine vibrates excessively, you should: balance the blade, tighten the blade mounting nut, clean the mower discharge chute, clean the underside of the mower deck, and tighten the engine mounting bolts.
Why Lawn-Boy Lawn Mower has uneven cutting pattern?
If your Lawn-Boy lawn mower has an uneven cutting pattern, ensure all four wheels are at the same height. Sharpen and balance the blade. Try changing your mowing pattern and clean the underside of the mower deck.
What to do if Lawn-Boy Lawn Mower discharge chute plugs?
If the discharge chute of your Lawn-Boy lawn mower keeps plugging, try raising the cutting height. Allow the grass to dry before mowing. Also, clean the underside of the mower deck.
General| Cutting Width | 21 inches |
|---|---|
| Deck Material | Steel |
| Starter | Recoil |
| Mulching Capability | Yes |
| Bagging Capability | Yes |
| Height Adjustment | 6-position |
| Mulch, Bag, Side Discharge | Mulch, Bag, Side Discharge |
| Drive Type | Self-Propelled, Rear-Wheel Drive |
| Wheel Size | 8 inches front, 10 inches rear |
Product can amputate hands/feet and throw objects. Follow all safety instructions to avoid serious injury or death.
Read manual, familiarize with controls, keep area clear, wear proper attire, check fuel before starting engine.
Do not run engine indoors, maintain footing, mow across slopes, wear safety glasses, stop engine after striking object.
Schedule for service items like fasteners, air filter, engine oil, housing, self-propelled drive, and blade.
Loosen knobs, lift top handle, tighten knobs, rotate handle, adjust handle height and self-propelled cable.
Install or remove cover plate for side discharge operation. Secure with wing screw after installing.
Push primer, hold blade control bail, pull starter handle. Repeat if engine fails to start.
Release blade control bail. Engine and blade will stop. See dealer if they do not.
Squeeze self-propelled bail to operate. Release to disengage. Mower has free-wheeling clutches.
Adjust each wheel individually with a lever. Heights range from 1 to 3.5 inches.
Maintain sharp blade, mow dry grass/leaves, clean deck underside, keep engine running, clean air filter.
Cut grass at appropriate heights, avoid cutting over 1/3 of blade. Mow tall grass in two passes, alternate direction.
Check blade balance by placing center hole over nail/shank. Grind end if it drops.
Remove blade nut and mulching fan. Remove blade from driver. Examine blade edges for nicks, angle, sharpness.
Stop engine, remove cover plate, place chute baffle, insert chute support rod, secure chute assembly.
Remove knob/bolt, position hanger clamp, secure bag hanger, close bag, position rear handles, grasp bag assembly handle.
Remove right handle knob, route bag rod, slide grass bag handle down chute flange, hook grass bag onto rod.
