LawnMaster CLMF4016K - Parts List

36
PARTS LIST
Key Number Drawing Number Description Quantity
1 Upper motor cover assembly 1.0
2 Lower motor cover assembly 1.0
3 Reduction gear box assembly 4.0
4 Motor drive plate 1.0
5 111308103 Rear wheel assembly (10.04") 2.0
5.1 111006119 Rear wheel cap 2.0
6 Cable clamp 1.0
7 111308104 Front wheel assembly (6.70" ) 2.0
7.1 111005107 Front wheel cap 2.0
8 Deck 1.0
9 211005103 Front axle 1.0
10 111005114 Front wheel clamp 2.0
11 Ballast assembly 1.0
12 211002110 Locating ring 1.0
13 111008119 Blade 1.0
14 211002111 Bolt 1.0
15 Height connecting rod 1.0
16 211063106 Safety key 1.0
17 Height adjustment plate assembly 1.0
18 111035144 Spring assembly 1.0
19 Height adjustment lever 1.0
20 Height adjustment handle 1.0
21 Right bracket assembly 1.0
22 211008121 Wheel shaft clamp 2.0
23 211008122 Rear axle 1.0
24 111093109 Rear debris sheild 1.0
25 Left bracket assembly 1.0
26 111008121 Safety door spring 1.0
27 111008122 Safety door shaft 1.0
28 211063108 Safety ap 1.0
29 111308111 Lower handle locking knob assembly 2.0
30 Right lower handle assembly 1.0
31 Left lower handle assembly 1.0
32 111308114 Upper handle locking knob assembly 2.0
33 111308110 Grass collection bag 1.0
34 Upper handle 1.0
35 Start/Stop bale switch 1.0
36 Switch box assembly 1.0
36.1 Switch 1.0
37 Cable clip 2.0
38 211063110 40V 4.0Ah Battery 1.0
39 211063111 40V Charger 1.0
Replacement parts highlighted in grey are available for after sales purchase. Replacement of repair or
internal parts should only be done by a qualied service professional. Please contact your authorized
service dealer or Customer Service at 866-384-8432.
