37
PARTS LIST
Replacement parts highlighted in grey are available for after sales purchase. Replacement of repair or
internal parts should only be done by a qualied service professional. Please contact your authorized
service dealer or Customer Service at 866-384-8432.
Key Number Part Number Description Quantity
1 Handle Assembly 1
2 111198146 Safety Key 1
3 Rear Wheel Assembly 2
3.1 Wheel Axle Ring 2
4 Cable Clamp 1
5 Front Wheel Assembly 2
6 Front Wheel Axle Assembly 1
7 Blade Mounting Plate 1
8 211078109 Blade 1
8.1 Blade Bolt 1
9 Rear Axle Assembly 1
10 Safety Door 1
11 Lower Handle Locking Knob 2
12 Left Lower Handle 1
13 Right Lower Handle 1
14 Upper Handle Locking Knob 2
15 211078118 Collection Bag 1
16 Upper Handle 1
17 Cable Clips 2
18 Mulch Plug 1
19 211070120 Charger 1
20 211078120 Battery 2
21 Mower Assembly 1
