PARTS LIST
Replacement parts highlighted in grey are available for after sales purchase. Replacement of repair or
internal parts should only be done by a qualied service professional. Please contact your authorized
service dealer or Customer Service at 866-384-8432.
Key Number Drawing Number Description Quantity
1 Handle Assembly 1
2 Motor Housing 1
3 211070103 Safety Key 1
4 Reduction Gear Box Assembly 1
5 Battery Compartment Assembly 1
6 PCB Controller Assembly 1
7 211070107 Rear Wheel Assembly 2
7.1 111054104 Wheel Axle Ring 2
8 Cable Clamp 1
9 Deck 1
10 211070109 Front Wheel Assembly 2
11 Front Wheel Axle 1
12 Wheel Axle Clamp 4
13 Ballast 1
14 211002110 Blade Mounting Plate 1
15 111193114 Blade 1
16 211002111 Blade Bolt 1
17 Connection Rod 1
18 Height Adjustment Lever 1
19 111005119 Tension Spring 1
20 211070111 Safety Flap 1
21 Height Adjusment Lever Cover 1
22 Rear Wheel Axle 1
23 111308111 Lower Handle Locking Knobs 2
24 111193126 Safety Door Spring 1
25 211070113 Safety Door 1
26 Left Lower Handle 1
27 Right Lower Handle 1
28 111308114 Upper Handle Locking Knobs 2
29 211070116 Collection Bag 1
30 Upper Handle 1
31 Bale Switch 1
32 Switch Box Assembly 1
32.1 Switch 1
33 111001111 Cable Clips 2
34 111193134 Mulch Plug 1
35 211070122 Battery 2
36 211070120 Charger 1
