KNOW YOUR CHIPPER
The safe use of this product requires an understanding of the information on the product and in
this Operator’s Manual as well as a knowledge of the project you are attempting. Before use of this
product, familiarize yourself with all operating features and safety rules.
Components
1. Push Paddle
2. Hopper Chute
3. Removable Upper Housing
4. Collection Bag Mounting
Hook
5. Collection Bag
6. Chassis (X2)
7. Hub Cap (X2)
8
1
2
3
4
6
5
8. Axle
9. Wheel (X2)
10. Cord Retainer
11. Power Cord
12. Lower Hopper Base
Section
13. Hopper Locking Knob
14. Handle
15. Motor Reset Button
16. On/O Switch
17. Hex Key (Stored Inside
the Chipper)
18. Screw (X2)
19. Cotter Pin (X2)
20. Washer (X2)
9
10
11
12
13
14
15 16
17 18 19 20
7
