21
■ Take out the hex key from the recess in the housing inside the chipper. Use the hex key to loosen
the screw counterclockwise. Remove the screw and the washer. Remove the blade from the blade
support (Fig. 10 & 11).
■ The blade can be reversed with the sharp edge in position as the cutting surface, or replace any
blunt or damaged blade as necessary.
■ Insert the washer and the screw. Then use the hex key to tighten the screw clockwise to secure the
blade to the blade support.
■ Put the hex key to the recess for future use.
■ Re-position the removable upper housing onto the lower hopper base section of the chipper. Secure
them into place using the hopper locking knob.
MAINTENANCE
Fig. 11Fig. 10
Blade
Screw
Screw
Washer
