11
FEATURES
Fig. 1
7
14
15
1
2
5
16
6
3
4
8
9
11
10
13
12a
12
NOTE: the above parts and their associated number/letters will be used throughout this manual to
identify parts.
KNOW YOUR LAWN MOWER (See Fig 1)
The safe use of this product requires an understanding of the information on the product and in this
operator’s manual as well as a knowledge of the project you are attempting.
Before use of this product, familiarize yourself with all operating features and safety rules.
1. Start/stop Bale Switch
2. Foam Grip
3. Upper Handle
4. Safety Switch Button
5. Cam locks
6. Collection Bag
7. Mulching Plug
8. Lower Handle
9. Safety Flap
10. Mower Carry Handle
11. Motor Housing
12. Side Discharge Door
12a. Side Discharge Chute
13. Cutting Height
Adjustment Lever
14. Deck
15. Front Wheels
16. Rear Wheels
