PARTS AND FEATURES
NPTGSP2617A PARTS LIST
Key
Number
Application Description Quantity
1 321001101 Cleva 26cc 2-Cycle Engine 1
2 321001102 Throttle-body & Starter Set 1
2.1 321001103 Throttle-body Set 1
2.2 321001104 Starter Set 1
2.2.2 321001106 Starter Switch Assembly 1
2.2.3 321001107 Stop Switch Set 1
2.2.4 321001108 PCB Assembly 1
3 321001109 Handle Spacer 2
4 141004102 Cable Clamp 2
5 321001111 Clutch Assembly 1
5.1 321005103 Screw 4
6 321001113 Wire Lock 1
7 321001114 7.2V Lithium-Ion Battery 1
8 321005104 Aluminum Upper Trimmer Shaft 1
9 321001116 Assist Handle Assembly 1
9.1 321001117 Assist Handle 1
9.2 321001118 Handle Clasp 1
9.3 321001119 Ball Joint 1
9.4 321001120 Ball Socket 1
10 321002102 Shaft Connection Sleeve 1
11 321005105 Aluminum Lower Trimmer Shaft 1
12 321005106 Debris Guard Bracket 1
13 321001121 *HDU%R[ 1
13.1 321005107 Screw 1
13.2 321001112 Bolt 1
13.3 321001122 Bolt 1
14 321001124 Cover Plate 1
15 321001125 Debris Guard 1
16 321001126 Rapid Reload Head Assembly 1
16.1 321001129 Rapid Reload Spool Spring 1
17 321001127 Charger 1
18 221003102 Shoulder Strap (Available Separately) 1
19 321001128 Shoulder Strap Clasp (Available Separately) 1
20 321004122 0+H[DJRQ6RFNHW:UHQFK 1
21 321004121 0+H[DJRQ6RFNHW:UHQFK 1
22 321004123 Open End Wrench 1
23 321004124 Socket Wrench 1
