2. Stand installation
Keep the foam underneath the monitor before attaching the stand.
1. Open the packaging, take out the product with the foam parts still attached, and gently place it on a
desktop or table. Use the included screwdriver and three no. 1 screws to fasten the base to the stem.
2. Remove the foam covering the back of the monitor, then press the button to remove the stand plate.
Use two no.1 screws to fasten the stand plate to the stem.
3. Insert the stand’s plate into the opening on the back of the monitor. It should click into place. Make sure
the stand is securely attached to the back of the monitor, then remove the remaining foam part from the
monitor and put it on a table or desk.
If needed, the stand can easily be detached from the monitor by pressing the button near the stand
plate. Make sure the monitor is laid on a flat surface before removing the stand.
