4. Product Overview
4.1 – Monitor Bu
ons
7
8
DP Connector
: Insert one end of the DP cable into the computer’s DP output
and connect the other end to the monitor’s DP port.
9
HDMI Connector : Insert one end of the HDMI cable into the computer’s HDMI
outpu t and connect the other end to the monitor’s HDMI port.
1
M Menu Button
: Press to display the OSD menu or enter sub-menus.
2
Down Button: Press to move down in the menus.
3
Up Button: Press to move up in the menus.
4
E Exit Button: Press to exit.
5
Power Button: Press to turn the monitor on/off.
6
LED Indicator: Changes colors to indicate status.
4.2 – Monitor Ports
10
DVI Connector
: Insert one end of the DVI cable into the computer’s DVI
outpu t and connect the other end to the monitor’s DVI port.
Audio Output
: Insert one end of the Audio cable into the computer’s Audio output
to receive the Audio signals from your monitor.
Eng-3
7 8 9
10
