Page 2 of 14 740100-00(5)
IMPORTANT
!
These instructions are presented in step-by-step sequence. It is very important that
installation begins with “1. Pre-Installation Site and Product Check” (page 3) and
continues as directed after each section.
WARNINGS
!
Always disconnect main power to the operator prior to replacing.
Control box contains no serviceable parts inside.
The Middle and Senior Swing Control Boxes are for use with the Middle and Senior Swing Power Operator
Systems, respectively. The systems can operate a single door (2810, 9530, 9540, 2910, 9730, and 9740
Series), a simultaneous pair of doors (2850, 9550, 2950, and 9750 Series), or an independent pair of doors
(2860, 9560, 2960, and 9760 Series).
ANSI/BHMA A156.19 Compliance
The Middle and Senior Swing Power Operator Systems are low energy products and must conform to the latest
version of ANSI/BHMA A156.19 (American National Standard for Power Assist and Low Energy Power Operated
Doors).
Installation Instructions
All installation instructions are valuable references and should be given to the building owner or maintenance
supervisor after installation is complete.
The Middle and Senior Swing Control Box installation instructions and the manufacturer’s instruction manual
accompanying any sensor must be referenced to ensure proper installation, setup, and operation.
CONTENTS
General Information ..................................................................................................................................... 2
Electrical Specifications .............................................................................................................................. 3
Pre-Installation Site and Product Check ...................................................................................................... 3
Installation................................................................................................................................................... 4
Wiring ......................................................................................................................................................... 4
Keypad Settings ......................................................................................................................................... 8
System Test...............................................................................................................................................12
Troubleshooting ..........................................................................................................................................13
Release for Service ....................................................................................................................................14
GENERAL INFORMATION
