SECTION 1 - SECURING MOUNTING PLATE ASSEMBLY TO FRAME
Prepare door and frame per template on page 4 for 4630 / page 5 for 4640. Be sure all holes are
located correctly before drilling and/or tapping. Mounting surface of frame must be vertically level.
Conduit access holes in frame are for If using concealed wiring
option, see step 2 below. , proceed to step 3.
Refer to correct template to determine proper location for conduit. Remove appropriate conduit
plugs, exposing conduit holes in back of mounting channel, as shown in . Attach 1/2" conduit
to mounting channel, as shown in . Place mounting channel into position on frame. Once
mounting channel is in position and flush on frame, insert fasteners and tighten securely.
1.
CONCEALED WIRING ONLY !
FOR SURFACE WIRING
2.
Fig. 1
Fig. 2
NOTE: Before beginning installation, determine which conduit connection option is to be used.
CONCEALED WIRING:
SURFACE WIRING: BEFORE
Both high & low voltage conduit lines should be run to door frame and
Made accessible through two holes to be drilled in frame per proper
template on page 4 or 5.
Mounting channel must be mounted to frame running high & low
voltage conduit lines to the operator.
Fig. 1
Fig. 2
NOTICE:
Electrical power must be disconnected
The following procedures involve electrical connections and running conduit for both high & low
voltage wiring. during the installation of the 4600
series door operator. It is also important to examine the proper template for your installation to
determine the mounting channel position and correct conduit location.
HIGH VOLTAGE
LOW VOLTAGE
NOTE: The conduit set-up shown is for
a 4630 mounting. Conduit location
will vary with other mountings.
LOW VOLTAGE
CONNECTION
HIGH VOLTAGE
CONNECTION
Fig. 3
Page 3
LOW VOLTAGE
CONNECTIONS
HIGH VOLTAGE
CONNECTIONS
HIGH VOLTAGE
CONNECTIONS
LOW VOLTAGE
CONNECTIONS
END CAP
REMOVED
FROM
THIS END
END CAP
REMOVED
FROM
THIS END
3.
CONDUIT THROUGH TOP OF MOUNTING CHANNEL:
Fig. 3
Position mounting channel on frame, conncect conduit and tighten securely.
After mounting plate is attached to frame, run 1/2" conduit
to access holes in top of mounting channel. Conduit should be
connected to channel as shown here in .
