OPTIONAL ACCESSORIES
LDICOASUB15PC – protective cover for ICOA SUB 15 A
LDICOASUB18PC – protective cover for ICOA SUB 18 A
TECHNICAL SPECIFICATIONS
Article number: LDICOASUB15A LDICOASUB18A
Product type: PA subwoofer
Type: Active
Large woofer: 15" 18"
Large woofer: 381 mm 457.2 mm
Woofer magnet: Ferrite
Woofer brand: Custom-made
Woofer voice coil: 3" 4"
Woofer voice coil: 76.5 mm 100 mm
Amplifier: Class D
Power (RMS): 600 W
Power (Peak): 2400 W
Frequency response: 36 Hz – preset dependent 29 Hz – preset dependent
Max. SPL (Peak): 118 dB 122 dB
Protection circuits: Peak Limiter, RMS Limiter, Excursion Limiter, Overheating, Overvoltage, Overcurrent
Input impedance: 18 kOhm
Input sensitivity: 0.3 V
Control elements: On/Off switch, rotary-push encoder
Display elements: Backlit LC display
Line inputs: 2
Line input connections: XLR/6.3mm jack combi sockets (balanced)
Line outputs: 2
Line output connections: XLR
AD/DA converter sampling frequency: 48 kHz
AD/DA converter resolution: 24 bit
Power supply: SMPS
Operating voltage: 100 V–240 V AC 50–60 Hz
Fuse: T6.3AL 250 V T8AL 250 V
Power consumption: 675 W
Ambient temperature (in operation): 0 - 40°C
Relative humidity: <60% (non-condensing)
Housing material: 0.71 inch multiplex
Housing design: Bass reflex
Installation flange for pole extension: M20 internal thread
Dimensions (W × H × D): 510 x 598 x 552 mm 626 x 672 x 637 mm
