LD LDMAUI28 - Specifications; Subwoofer Specifications; Mid;Hi System Specifications; Amplifier Module Specifications

16
Product number: LDMAUI28
Product type: PA system
Type: active
Colour: black
Max. SPL (continuous): 115dB
Max. SPL (peak): 123dB
Frequency response: 45 - 20,000Hz
Dispersion (H x V): (horizontal) 120°
Weight: 35kg
Subwoofer
Low/mid driver dimensions: 2 x 8"
Low/mid driver dimensions (mm): 2 x 203mm
Woofer magnet: Ferrite
Woofer brand: Custom-made
Cabinet construction: vented, V Construction
Cabinet material: 15 mm Plywood
Cabinet surface: Dura Coat LX Texture Paint
Subwoofer width: 390mm
Subwoofer height: 450mm
Depth Subwoofer: 510mm
Subwoofer features: Custom-made multipin connector for vertical array
Mid/Hi System
Midrange size: 16 x 3"
Midrange size: 16 x 76mm
Midrange magnet: Neodymium
Midrange brand: Custom-made
Tweeter dimensions: 1"
Tweeter dimensions (mm): 25mm
Tweeter magnet: Ferrite
Tweeter brand: Custom-made
Loudspeaker inputs: 1
Speaker input connections: Custom-made multipin
Cabinet construction mid/high: Closed
Mid/Hi system cabinet material: aluminium
Mid/Hi system cabinet surface: Paint
Mid/Hi system width: 110mm
Mid/Hi system height: 790mm
Mid/Hi system depth: 90mm
Mid/Hi system features: Vertical array with 4-way amping and extremely broad dispersion characteristic
Amplifier Module (integrated in Subwoofer)
Amplifier: 5-way Class A/B
Amplifier Output System (RMS): 400W
Amplifier Output System (Peak): 1600W
Protection circuits: Dual limiter
Cooling: Aluminium heat sink
Controls: Subwoofer Volume, mains switch (on/off), volume
Indicators: protect (protection circuit engaged), limit, signal, Power, Lock
SPECIFICATIONS / TECHNISCHE DATEN / CARACTÉRISTIQUES / CARACTERÍSTICAS TÉCNICAS /
SPECYFIKACJE / SPECIFICHE
EN
