121
FUNzIONAMENTO / SPECIFICHE:
LD SUB88 LD SUB88A LD SUB10A
Product Installation speaker Installation speaker Installation speaker
Type passive active, bandpass active, bass reflex
Loudspeaker 2x8“ woofer 2x8“ woofer 10“ woofer
Amplifier - Class A/B Class A/B
Load capacity (RMS
/ max.)
2 x 100/180W 150W 3 x 120W
Frequency range 40Hz to 120Hz 40Hz-120Hz 40Hz-120Hz
SPL 92 dB 92 dB 97 dB
Max. SPL 115dB 115 dB 118 dB
Protection circuit - excess current
Short circuit, Over
current, Clip Limiter
Line in - sym. XLR / 6.3 mm Jack
-sym. XLR / 6.3 mm
Jack
Line out - - binding post-
Power Input - 220-240 V AC 220-240 VAC
Impedance 2 x 8ohms - -
Terminals Clamp-type connection - -
Cabinet material 15 mm MDF 15 mm MDF 15 mm MDF
Cabinet surface textured paint textured paint textured paint
Dimension (WxHxD) 600 x 250 x 350 mm 600 x 250 x 350 mm 505 x 345 x 425 mm
Weight 11 kg 4.1 kg 21 kg
Accessories - -
Ergonomic milled
handles, Threaded
flange (M20)
CONNESSIONE
Spegnere l'LD SUB10A (OFF) prima di collegarlo ad altri dispositivi. Una volta collegati tutti i cavi necessari e
abbassata la manopola MAIN LEVEL, si può accendere il dispositivo sorgente. A questo punto si può accendere
anche l'LD SUB10A (ON). Girare la manopola MAIN LEVEL in senso orario fino a raggiungere il volume desiderato.
