73
ESPECIFICACIONES TÉCNICAS:
LD SAT42(W) LD SAT242(W) LD SAT62(W) LD SAT82(W) LD SAT62A
Product Installation speaker Installation speaker Installation speaker Installation speaker Installation speaker
Type passive passive passive passive active/bass reflex
Loudspeaker
4“ woofer & 1“ silkdome
tweeter
2 x 4“ woofer & 1“ silkdo-
me tweeter
6.5“ woofer & 1“
silkdome tweeter
8“ woofer & 1“ horn
tweeter
6.5” woofer & 1“
silkdome tweeter
Amplifier - - - - Class A/B
Dispersion 60° x 60° 60° x 60° 60° x 60° 60° x 60° 60° x 60°
Load capacity (RMS
/ max.)
60/100W 100/180W 80/130W 120/200W 50W
Frequency range 75Hz-20.000Hz 75Hz-20.000Hz 55Hz-20.000Hz 50Hz-20.000Hz 55Hz-20.000Hz
SPL 85 dB 88 dB 89 dB 93 dB 89 dB
Max. SPL 103 dB 108 dB 108 dB 114 dB 108 dB
Protection circuit - - - - excess current
Line in - - - -
sym. XLR / 6.3 mm
Jack
Line out - - - - sym. XLR
Power Input - - - - 220-240 V AC
Impedance 16ohms 8ohms 16ohms 8ohms -
Terminals Clamp-type connection Clamp-type connection Clamp-type connection Clamp-type connection -
Cabinet material 12 mm MDF 12 mm MDF 12 mm MDF 15 mm MDF 12 mm MDF
Cabinet surface textured paint textured paint textured paint textured paint textured paint
Dimension (WxHxD) 140 x 230 x 125 mm 140 x 378 x 135 mm 200 x 320 x 200 mm 247 x 410 x 243 mm 200 x 320 x 205 mm
Weight 2.7 kg 4.1 kg 4.1 kg 8.5 kg 6 kg
Accessories
4 M6 rigging/mounting
points, mounting brackets
4 M6 rigging/mounting
points, mounting brackets
4 M6 rigging/moun-
ting points, mounting
brackets
4 M6 rigging/mounting
points, mounting brackets
4 M6 rigging/moun-
ting points, mounting
brackets
