BACK PANEL ACTIVE SPEAKER:
LD SUB10A
1
MAIN LEVEL
Preset of the main level of the system - subwoofer will be adjusted too, corresponding the preset of the SUB
LEVEL.
2
SUB PHASE
Phase invertation switch to invert the Phase of the Subwoofer (0° / 180°) if necessary due to an difficult
installation.
3
SUB LEVEL
Preset subwoofer level proportionally to the satellite level. We recommend at the standard setting 12:00
o‘clock.
4
LINE DIRECT OUTPUT (LEFT / RIGHT)
Direct symetrical Line Input for XLR connectors.
5
LINE INPUT
Symetrical Line Input for XLR connectors and 6.3 mm jacks.
6
SPEAKER OUTPUT (LEFT / RIGHT)
7
POWER CONNECTION SEAT
Power connection seat 240 V (IEC power connector) and fuse seat. Replacement of fuse only if power
connection is disconnected. If fuse blows repeatedly please contact authorized personel for servicing.
8
POWER SWITCH
ON / OFF switch. Please switch connected devices to ON first and to OFF after switching the system.
