LDSAT42G2(W)
Product type Installation Speakers
Type: passive
Woofer size: 4 "
Woofer size: 101 mm
Woofer magnet: ferrite
Woofer brand: custom made
HF driver size: 1 "
HF driver size: 25 mm
HF driver magnet: ferrite
HF driver brand: custom made
Dispersion angle (H x V): 60 x 60 °
Power output (RMS): 60 W
Power output (peak): 240 W
Frequency response: 75 Hz - 20,000 Hz
Sound-pressure level (1 W/1 m): 85 dB
Max SPL: 103 dB
Impedance: 16 ohms
Protection: HF driver
Speaker inputs: 1
Speaker input connections: Clamp connector
Cabinet material: 12 mm MDF
Cabinet surface: textured coating
Cabinet colour: black (LDSAT42G2) / white (LDSAT42G2W)
Cabinet type: closed
Dimensions (W x H x D): 140 x 230 x 125 mm
Weight: 5 kg / pair
Other features: Wall bracket included
