Step
Page 6
Hardware Used In This Step
Qty
ID #
1
D
5mm Hex Wrench
1. Attach the to the as shown using the
( ).
2. Please note the ( ) may have to be turned slightly to start the bolts threading.
3. Install the with starting and ending flush with the end of the support cleats
attached to your ( ).
4. First install ( ) into each end of the closest to the and
. Arrange the remaining so that they are evenly spaced along the
. Insert the ( ) into both ends of all remaining , permanently
connecting the to the cleats of the .
Bed Rails Loft Bed Ends Long Connecting Bolts
A
Barrel Nuts G
Slat Pack Slats
Bed Rails Figure 1
Wood Screws E Slats Headboard
Footboard Slats Bed
Rail Wood Screws D Slats
Slats Bed Rails
1" Wood Screw
Qty
E
ID #
30
5/16" X 4-1/2” Connecting Bolt
Qty
ID #
A 8
Figure 1
1” Wood Screw
To Next Page
