LEAB ABC 1215 - LED Display on the Charger

Installation Instructions LED Display on the Charger
Page 16 of 18
Charging the Battery
The charger begins to charge the battery as soon as it is switched on.
Switching off the Device
To switch off the charger, perform the following step:
1. To turn off the device, press the on/off switch in position 0.
The device is switched off.
11 LED Display on the Charger
Status
Description
Measure
Steady
light
orange
Battery is charging. The
charger is in the main
charging phase.
Steady
light
green
Battery is fully charged,
charger is in trickle charge
phase.
Charger can be switched off and the
battery can be used.
Steady
light
red
Error, overheating
Check battery connection
Measure battery voltage
Disconnect the device from the
battery and allow it to cool down
Flashing
red
Timeout in the main
charge phase, charging
interrupted.
Check battery
Select larger charger
Consumer too large: Switch off
consumer when charging
For devices without an on/off switch, the device switches off as
soon as the mains plug is disconnected from the 230-V mains.
