6.2.2. Variable Tracking
Ratio
Mode, Constant
Voltage
Operation.
a. Push
the
+
25V
METER selector button
(3).
b. Ensure that the
TRACKING
RATIO selector
switch
(7)
is
in
the
VARIABLE
position.
c. Turn the CURRENT controls
(12)
and
(14)
to
their fully
clockwise
positions.
d. Turn the REFERENCE/-^ 25V control
(6)
to the desired
positive
voltage,
e. Push the TRACKING —25V METER selector button
(4).
f. Using the TRACKING RATIO control
(9),
set the
—25
V
source
to the desired
negative
voltage.
After the TRACKING RATIO control
(9)
has
been set,
turning
the
REFERENCE/
F
25V
control
(6)
will cause
the —25V source to change its voltage with respect to
the
+25V
source
by the established ratio,
g.
Press the REFERENCE ~'“25V METER
selector button
(3).
h. The load may now be connected to the supply.
6.2.3.
Operation
Using Current Limiting
a. Set the CURRENT controls (i2) and
(14)
to their fully
counterclockwise
positions,
b.
Set the ±25V
sources
to the desired
voltage
by
using
one of the procedures
above.
Disregard the step
involv-
ing turning the current controls fully clockwise.
c. Ensure
that
the REFERENCE
+25V
METER
selector
button
(3)
is pressed in.
d. Short circuit the COM and +25V terminals
(10)
and
(11).
The voltmeter will indicate zero
volts.
e. Set
the
+0.5A
(-1-
1 A
forthe
EPS-
152)
CURRENT con-
trol
(12)
to the desired level of current limiting as indi-
cated on the AMMETER
(23).
Rotating
the
CURRENT
control
(12)
clockwise
raises
the current limit setpoint.
f.
Remove
the short circuit from the COM and
+
25V
ter-
minals
(10)
and
(11).
g.
Press the
TRACKING
—25V METER
selector
button
'
(4),
h. Short
circuit
the
COM
and
—25V terminals
(10)
and
(13).
The voltmeter will indicate zero volts,
i . Set the
-
0 . 5 A
(
- I A for the LPS-
152)
CURRENTcon-
trol
(14)
to the level of current limiting desired as indi-
cated on the AMMETER
(23).
Rotating the CURRENT
control
(14)
clockwise raises the current limit setpoint.
7. CALIBR,
The following instructions detail the calibration of the
meters
and
voltage
outputs for the LPS- 1 5
1/152
power sup-
ply, Also included are transformer tap changing directions
so
that the ptiwer supply may
be used
with a line
voltage
other
than 120Vac,
7
A
PREPARATION
I . Adjustment of Meter Mechanical
Zero.
a.
Turn
the
powder
supply off and
allow
one minute for all
capacitors to
discharge.
b.
On the
voltmeter,
turn the zero adjust screw
(20)
so that
the pointer indicates exactly zero.
c. When the
pointer is
at zero, rotate the
screw
a small
amount in the opposite direction to the direction it was
last turned in step b to relieve movement tension.
j.
Remove
the short circuit
from the COM
and -25V ter-
minals
(10)
and
( 13).
k. Press the REFERENCE
+25V
METER selector
button
(3).
l. The load may now be connected to the supply.
6.2.4.
Voltage
Settings
Above
25V,
Constant
Voltage
Operation
.
Used together,
the
±25V
sources
will
produce a maximum
output of 50V. However, in this mode the 6V output
may not be used.
a. Press the REFERENCE -^25V METER selector button
(3).
b. Set CURRENT controls
(12)
and
(14)
to their fully
clockwise
position.
c. Ensure that the TRACKING RATIO selector
switch
(7)is in the FIXED position.
d
Turn
the
REFERENCE/
F 25V control
(6)
such the the
voltmeter
(18)
indicates one -half of the desired voltage
value. Remember that the
voltmeter
will only indicate
one-half of the voltage value between the ±25V output
terminals
(
1
1 )
and
(13).
e.
The load
may
now be connected to the supply. The
maximum current
available
at
50V
is
OJA
(1
.OA
with
the LPS-
152).
6.2.5.
Voltage
Settings
Above
25V
with Current
Limiting.
a. Set the CURRENT controls
(12)
and
(14)
to their fully
counterclockwise
positions.
b. Set the +25V sources for above 25V operation by using
the
procedure
above.
Disregard
the
step
involving turn-
ing the current controls fully clockwise.
c. Ensure that the REFERENCE +25V METER selector
button
(3)
is pressed in.
d.
Shon circuit
the
+25V
and
-25V
terminals
(II) and
(13).
The voltmeter will indicate zero volts.
e .
Set the
F
0.
5
A
(
+
1 A
for
the
LPS-
152)
CURRENT
con-
trol
(12)
to the desired
level
of current limiting as indi-
cated on
the
AMMETER
(23).
Rotating
the
CURRENT
control
(12)
clockwise raises the current limit setpoint.
f. Remove the
short
circuit
from the
F25V
and
—
25V
ter-
minals
(1
i) and
(13).
g.
The
load may
now
be
connected to the
supply.
PROCEDURES
