-9-
STO NE 180
Cable 4x1,5 mm
Color
STONE 24
Cable 2x1,5 mm
Color
Common Blue Positive motor Red or Green
Moto r O PEN Black Negative moto r Black or Brown
Moto r CLOSE Brow n
Gro und Y ellow- Green
Capacitor connection
- In the gearmotor STONE180 connect the 12uF capacitor between the
black wire (Open) and the brown wire (Close) of the electric engine.
Limit switches cable
The device is equipped with two magnetic Limit switches. From the
Limit switches block three wires come out. In the following table the
data concerning the Limit switches cable, required for the connection
to the control board, are reported.
Manual unblocking
The manual unblocking causes the release of the device
from the wing, allowing the manual displacement of this one. It can be
used in case of electric voltage lack or of installation failure. The
unblocking is made through a key that is to be kept by user in a sure and
easily reachable place. In order to obtain the unblocking of the device,
proceed in the following way:
- Insert the socket spanner into the hole fitted on the traction arm (fig.17).
- Turn the socket spanner in the direction indicated in fig.17, then open the
wing of the gate by hand.
- To lock, bring the wing back to the hooking position with the traction arm.
- Turn the socket spanner in the opposite direction and simultaneously
push the wing to hook it.
Cable 3 x 1,5 mm Colour
Common Blue
Limit switch OPENING Black
Limit switch CLOSING Brown
