TECHNICAL DATA STONE 180 STONE 24
Power supply 230 Vac - 50 Hz 24 Vdc
Nominal current 1,2 A 5,2 A
Electric power 1/3 HP 90 W
Maximum gate weight 350 Kg 250 Kg
Maximum gate length 2,5 mt 2,5 mt
Torque 330 Nm 270 Nm
Thermal protection 150 °C -
Operating temperature from -20 to +60°C from -20 to +60°C
Insulation degree IP67 IP67
Opening time 90° 15 Sec 15 Sec
Workingcycle 50% 90%
Weight 15 Kg 15 Kg
