7.4 Attaching the
push handle
The push handle is attached to the Hi-low
chassis by inserting the two lower stems
into the receiving tubes as shown. The push
handle has safety poppers (A), which need to
be pressed in when inserting the lower stems.
Push the stems in until the poppers protrude
from the other end of the receiving tubes.
Secure the handle in place by tightening the
locking knobs (B).
Check these regularly to make sure the
knobs are tight, particularly if you are
moving the product unit along corridors
that may have uneven or sloping
surfaces.
B
A
