7.7 Attaching the
lateral supports
While holding the components together,
remove the plastic knob and washer. Align the
plastic angle adjuster mouldings and lateral
bracket with the slot in the backrest and refit
the washer and plastic knob.
7.6 Attaching the
shoulder section
To attach the shoulder section to a Size 1
Mygo, remove the headrest mounting bracket
by removing the bolts (A). Insert the shoulder
section bracket and supplied spacer plate
between the backrest and the headrest
mounting bracket. Bolt back together. Secure
the two metal tabs with additional screws (B)
provided with the new spacer plate.
The screws are attached from the front.
Check it is securely fastened.
A
A
B
B
