7.13 Attaching the
tray
7.12 Attaching the
armrests
The tray is attached to the seat by inserting
the tray tubes through the centre of the
armrest. Once the tray is located in the
position the knob (A) should be tightened
securely.
Open the receiving bracket by loosening the
ratchet handle (A) and insert the armrest.
Ensure that the popper (B) has locked
securely. Retighten the ratchet handle.
A
A
B
