9.3 Adjusting the chest
and hip supports
To adjust the chest and hip support rotate
knob (A) in a clockwise direction and rotate
knob (B) in an anticlockwise direction as
shown. Set to the required position and then
retighten. The chest support can only be
adjusted in angle and depth.
Always use caution to ensure fingers do
not become trapped when adjusting the
chest and hip supports.
9.4 Lateral supports
Loosen the hand knob (A) to adjust the width
of the lateral supports and retighten when
you have achieved the desired position. If,
the lateral supports are attached with bolts
instead of hand knobs they can be adjusted
with the multi tool.
Always use caution to ensure fingers do
not become trapped when adjusting the
lateral supports.
A
A
B
