The Pivot Chassis can be easily folded
for storage or transportation. To unfold,
release the levers (A) shown by pressing
them together, rotate the rear tubes until
the levers engage in the locked position.
To fold the chassis simply reverse this
procedure.
Always remove the standing support
frame before trying to fold the chassis.
Always use caution to ensure fingers do
not become trapped when folding and
unfolding the pivot chassis.
The Squiggles Stander can be used as a
prone, supine or upright stander and has
been designed to fit with three chassis
options, the Mobile chassis, Pivot chassis
and the Easel chassis.
7.1 Folding and unfolding
the pivot chassis
7.2 Attaching the
stander to its chassis
A
A
